NEW notch for better hex alignment. Added ring for key stability and key design for easy installation and alignment. Used with the Densah® Burs G3 and Extra-Large G-Stop® Gauge/Keys for guided surgery with the Densah Burs.

The specifically designed "C" shape helps with irrigation flow and allows better luxating motion with the Densah.


  • Compatible with Extra-Large G-Stop® Keys
  • Used for Implant Diameters up to 6.2 mm
  • C-Guide Outside Diameter: 8.1 mm
  • C-Guide Inside Diameter: 7.20 mm
  • C-Guide Height: 7.25 mm


  • Extra-Large G-Stop Gauge/Keys
  • Generation 3 (G3) Densah Bur
  • Compatible with Tapered Pilot Drill, VT1525, VT1525-S, VT1828, VT1828-S, VS2228, VT2535, VT2535-S, VT2838, VT2838-S, VS3238, VT3545, VT3545-S, VT3848, VT3848-S, VS4248, VT4555, VT4858, VS5258
Current stock: 0

C-Guide® Sleeve-Extra-Large
