VS8^® Bur
PRESERVE THE BONE - ENHANCE THE HOST™

Optimized for Dual Mode Operation

Use with external irrigation as final step in placing parallel and tapered walled dental implants with diameters 4.0, 4.2, 4.3 mm. The proprietary flute design allows the bur to work in 2 modes:

• Cutting Mode (Clockwise rotation) at 800-1500 RPMs
• Densifying Mode (Counterclockwise rotation) at 800-1500 RPMs
• Laser Markings to indicate depth at 3, 5, 8, 10, 11.5, 13, 15, 18, and 20mm

Specifications:

• Total Length: 37mm
• Apical Diameter: 3.2mm
• Coronal Diameter: 3.8mm
• Average Diameter: 3.5mm
• Right Angle Latch Type Connection
